Overview

Ocal C14-G PVC Coated Shallow Channel Strut Gray

Product Specifications

• UPC: 70450835805
• Height: 13/16 Inch
• Material: Strip Steel
• Process: Cold Formed Hot Rolled Pickled
• Finish: PVC Coated
• Additional Information: Color Gray
• Catalog Number: C14-G
• Type: Shallow, Single
• Number Of Channels: 1
• Configuration: Solid
• Applicable Standard: UL, CSA
• Thickness: 14 Gauge
• Length: 10 Ft
• Width: 1-5/8 Inch
• Catalog Description: PVC COATED SHALLOW CHANNEL STRUT, 13/16 INCH DEPTH, 14 GAUGE, 10 FOOT LONG, STEEL, DARK GRAY
• Category: Channel & Strut
• Full Technical Description: Shallow, Single Type; Strip Steel Material; PVC Coated Finish; 10 ft; 1-5/8 Inch; 13/16 Inch; Solid Configuration; UL, CSA Applicable Standard; 14 Gauge Thickness; Cold Formed Hot Rolled Pickled Process; 1 Channel(S); OCAL-BLUE[R] Brand; Color Gray
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Ocal
• Sub Category: Channel/Strut
• Unspsc: 30101804
• UPC 12 Digit: 704508358051
• SKU Name: ocal c14g

Resources

• Manufacturer Spec Sheet
