Ocal XJG64-G Expansion Coupling 2", Length 11.25" Gray

Overview

Ocal XJG64-G Expansion Coupling 2", Length 11.25" Gray

Product Specifications

• UPC: 70450841772
• Ground Type: Internally Grounded
• Material: PVC Coated Malleable Iron (Body), Tinned Copper Braid (Bonding Jumper), PTFE/Synthetic Fiber (Packing)
• Approval: UL
• Used On: Rigid Conduit
• Additional Information: Height 4.18 Inch; Color Dark Gray
• Catalog Number: XJG64-G
• Brand Name: Ocal
• Model: XJG
• Trade Size: 2 Inch
• Diameter: 3.86 Inch
• Length: 11.25 Inch
• Maximum Movement: 4 Inch
• Constructional Feature: Corrosion Resistant
• Catalog Description: PVC COATED XJG RIGID CONDUIT EXPANSION COUPLING WITH INTERNAL BONDING JUMPER, 2 INCH/53 METRIC, BODY IS MALLEABLE IRON WITH ZINC PLATING, INTERNAL BONDING JUMPER IS TINNED COPPER BRAID, PACKING PTFE/SYNTHETIC FIBER MATERIAL, 4 INCH/101.60 MILLIMETERS MOVEMENT, DIAMETER 3.86 INCH/98.04 MILLIMETERS, LENGTH 11.25 INCH/285.75 MILLIMETERS, HEIGHT 4.18 INCH/106.17 MILLIMETERS, GRAY
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: PVC Coated Malleable Iron (Body), Tinned Copper Braid (Bonding Jumper), Ptfe/Synthetic Fiber (Packing) Material; 11.25 Inch; Rigid Conduit Used on; 4 Inch Max. Movement; UL Approval; 3.86 Inch Diameter; Internally Grounded; 2 Inch Trade Size; Corrosion Resistant; Height 4.18 Inch; Color Dark Gray; XJG Model
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Ocal
• Sub Category: Rigid/EMT Expansion/Deflection Joint
• Unspsc: 39131707
• UPC 12 Digit: 704508417727
• SKU Name: ocal xjg64g

Resources

• Manufacturer Spec Sheet
