Ocal XJG88-G Expansion Coupling 3", Length 16.12" Gray

Overview

Ocal XJG88-G Expansion Coupling 3", Length 16.12" Gray

Product Specifications

• UPC: 70450841785
• Ground Type: Internally Grounded
• Material: PVC Coated Malleable Iron (Body), Tinned Copper Braid (Bonding Jumper), PTFE/Synthetic Fiber (Packing)
• Approval: UL
• Used On: Rigid Conduit
• Additional Information: Height 5.25 Inch; Color Dark Gray
• Catalog Number: XJG88-G
• Brand Name: Ocal
• Model: XJG
• Trade Size: 3 Inch
• Diameter: 4.96 Inch
• Length: 16.12 Inch
• Maximum Movement: 8 Inch
• Constructional Feature: Corrosion Resistant
• Catalog Description: PVC COATED XJG RIGID CONDUIT EXPANSION COUPLING WITH INTERNAL BONDING JUMPER, 3 INCH/78 METRIC, BODY IS MALLEABLE IRON WITH ZINC PLATING, INTERNAL BONDING JUMPER IS TINNED COPPER BRAID, PACKING PTFE/SYNTHETIC FIBER MATERIAL, 8 INCH/203.20 MILLIMETERS MOVEMENT, DIAMETER 4.96 INCH/125.98 MILLIMETERS, LENGTH 16.12 INCH/409.45 MILLIMETERS, HEIGHT 5.25 INCH/133.35 MILLIMETERS, GRAY
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: PVC Coated Malleable Iron (Body), Tinned Copper Braid (Bonding Jumper), Ptfe/Synthetic Fiber (Packing) Material; 16.12 Inch; Rigid Conduit Used on; 8 Inch Max. Movement; UL Approval; 4.96 Inch Diameter; Internally Grounded; 3 Inch Trade Size; Corrosion Resistant; Height 5.25 Inch; Color Dark Gray; XJG Model
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Ocal
• Sub Category: Rigid/EMT Expansion/Deflection Joint
• Unspsc: 39131707
• UPC 12 Digit: 704508417857
• SKU Name: ocal xjg88g

Resources

• Manufacturer Spec Sheet
