Overview

High-pressure capability for demanding applications, Corrosion-resistant materials for extended lifespan, Easy installation with no special tools required

Product Specifications

• Category: Large Terminals & Connectors
• Full Technical Description: EC Grade High Purity Aluminum Material; 3 Inch Overall Length; Acsr/Aluminum/Copper Conductor Material; 9/16 Inch Stud Size; BG, 5/8 or 243 Die Index; 1-3/32 Inch L X 7/8 Inch W X 1/4 Inch Thk Pad Size; 1 Pad Hole(S); 6 AWG ACSR Conductor Size; 4 AWG Solid, 6 AWG Stranded Aluminum/Copper Conductor Size; Aluminum PENN-CRIMPS[R] Brand; Conductor Size 4 AWG Compact; FKLA Model
• Manufacturer: Penn-Union Corp.
• Manufacturer Brand: Penn-Union Corp.
• Sub Category: Compression Terminal
• UPC 12 Digit: 785037344340
• SKU Name: FKLAW4S PENNUNION
