Robroy PRLBY55 1-1/2-Inch PVC-Coated Ferrous Metal LBY Service Entrance Elbow

Product Specifications

• Catalog Number: PRLBY55
• UPC: 784011208289
• Full Technical Description: product type: LBY service entrance elbow; trade size: 1-1/2 inches; feed type: feed-through; configuration: 90-degree elbow; body material: ferrous metal; exterior finish: nominal 0.040-inch, 40-mil gray PVC coating; interior finish: nominal 0.002-inch, 2-mil red urethane coating; Dimension A: 4.50 inches; Dimension B: 3.46 inches; nominal weight: 2.7 lb; sealing sleeves provided on conduit openings; molded PVC gasket seals the fitting cover to the body; hazardous-location rating: Class I, Divisions 1 and 2, Groups C and D; Class II, Division 1, Groups E, F, and G; Class II, Division 2, Groups F and G; Class III; application: connects service entrance and vertical weatherhead conduit runs, changes conduit direction by 90 degrees where space is limited, and provides a pull outlet; compatibility: threaded PVC-coated conduit systems
• Made In Usa: No
• Manufacturer: Robroy Industries
• Manufacturer Brand: Plasti-Bond
• Unspsc: 39131707
