Overview

Robroy PRUNF905 3-1/2-Inch PVC-Coated Ferrous Metal Female/Female UNF Union

Product Specifications

• Catalog Number: PRUNF905
• UPC: 784011207794
• Full Technical Description: product type: UNF hazardous-location conduit union; trade size: 3-1/2 inches; fitting configuration: female-to-female; connection type: threaded; body material: ferrous metal; exterior finish: nominal 0.040-inch, 40-mil gray PVC coating; interior finish: nominal 0.002-inch, 2-mil red urethane coating; sealing sleeves provided on all conduit openings; molded PVC gasket seals the fitting; nominal weight: 8.2 lb; approvals and standards: UL 1203, file E476062, and CSA C22.2 No. 30; hazardous-location ratings: Class I, Divisions 1 and 2, Groups C and D; Class II, Division 1, Groups E, F, and G; Class II, Division 2, Groups F and G; Class III; application: joins two threaded conduit sections and permits future modifications or disassembly without rotating the conduit runs; suitable for hazardous and corrosive conduit systems
• Made In Usa: Yes
• Manufacturer: Robroy Industries
• Manufacturer Brand: Plasti-Bond
• Unspsc: 39131707
