T&B 2RE6 Insulated Nylon Butt Splice 6 Len 1.85 Dia

Overview

T&B 2RE6 Insulated Nylon Butt Splice 6 Len 1.85 Dia

Product Specifications

• UPC: 78621089466
• Insulation Type: Nylon Insulated
• Color: Blue
• Material: Electro Tin Plated Copper
• Temperature Rating: 105 Deg C
• Standard Package: 20 per Pack
• Approval: UL, CSA
• Additional Information: Applicable Standard MIL-T-7928
• Catalog Number: 2RE6
• Brand Name: Tefzel[R]
• Type: Butt
• Voltage Rating: 600 Volt
• Length: 1.85 Inch
• Barrel Outer Diameter: 0.45 Inch
• Maximum Insulation Diameter: 0.42 Inch
• Conductor Size: 6 AWG
• Catalog Description: NYLON-INSULATED BUTT SPLICE, LENGTH 1.85 INCHES, WIDTH .45 INCHES, MAXIMUM INSULATION DIAMETER .420, WIRE RANGE #6, COLOR BLUE, COPPER, TIN PLATED
• Category: Splicing & Terminating Kits
• Full Technical Description: Butt Type; Electro Tin Plated Copper Material; Blue Color; 1.85 Inch; 0.42 Inch Max. Insulation Diameter; UL, CSA Approval; 600 Volt Voltage Rating; 105 Deg C Temperature Rating; 20 Per Pack Standard Package; 6 AWG Conductor Size; Nylon Insulated Insulation Type; 0.45 Inch Barrel Outer Diameter; Applicable Standard mil-T-7928
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Splice Connector
• Unspsc: 39121449
• UPC 12 Digit: 786210894669
• SKU Name: t&b 2re6
