T&B 54516 Copper Tin Plated 2-Way Connector Splice Standard 400 Blue

Overview

T&B 54516 Copper Tin Plated 2-Way Connector Splice Standard 400 Blue

Product Specifications

• UPC: 78621054516
• Outer Diameter: 0.93 Inch
• Body Material: High Conductivity Electro Tin Plated Wrought Copper
• Approval: UL, CSA
• Additional Information: Die Code 76
• Catalog Number: 54516
• Type: 2-Way
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 400 KCMIL (Code)
• Conductor Material: Copper
• Color Code: Blue
• Barrel Type: Standard
• Length: 2.75 Inch
• Catalog Description: COPPER TWO-WAY CONNECTOR SPLICE, STANDARD BARREL, MAX 35KV, WIRE SIZE 400 KCMIL, TIN PLATED, DIE CODE 76, DIE COLOR CODE BLUE
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 2.75 Inch; 0.93 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; High Conductivity Electro Tin Plated Wrought Copper Body Material; 400 kcmil (Code) Conductor Size; Blue Color Code; Standard Barrel Type; Die Code 76
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210545165
• SKU Name: t&b 54516

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
