T&B 54854BE 2-Hole Long Barrel 1/4-5/8 Holes No4

Product Specifications

• UPC: 78621089798
• Stud Size: 1/4 Inch
• Color: Gray
• Die Index: 29
• Material: High Conductivity Electro Tin Plated Wrought Copper
• Overall Length: 2.31 Inch
• Approval: UL, CSA
• Additional Information: Includes Blind End Inspection Hole
• Catalog Number: 54854BE
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Material: Copper
• Conductor Size: 4 AWG (Code)
• Barrel Type: Long, Straight
• Pad Size: 1.19 Inch Length x 0.52 Inch Width x 0.1 Inch Thickness
• Number Of Pad Holes: 2
• Pad Hole Spacing: 5/8 Inch
• Catalog Description: COPPER TWO-HOLE LUG, LONG BARREL, BLIND END, MAX 35KV, WIRE SIZE #4 AWG, 1/4 INCH BOLT SIZE, 5/8 INCH HOLE SPACING, TIN PLATED, DIE CODE 29, DIE COLOR CODE GRAY
• Category: Large Terminals & Connectors
• Full Technical Description: High Conductivity Electro Tin Plated Wrought Copper Material; Gray Color; 2.31 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; 4 AWG (Code) Conductor Size; 1/4 Inch Stud Size; 29 Die Index; 1.19 Inch Length X 0.52 Inch Width X 0.1 Inch Thickness Pad Size; 2 Pad Hole(S); 5/8 Inch Pad Hole Spacing; Long, Straight Barrel Type; Includes Blind End Inspection Hole
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210897981
• SKU Name: t&b 54854be
