T&B 60147 4/0Awg White 1-Hole Aluminum/Copper Lug

Overview

T&B 60147 4/0Awg White 1-Hole Aluminum/Copper Lug

Product Specifications

• UPC: 78621060147
• Stud Size: 5/16 Inch
• Color: White
• Die Index: 66
• Material: Electro Tin Plated Wrought Aluminum
• Overall Length: 3.53 Inch
• Approval: UL, CSA
• Catalog Number: 60147
• Model: 601
• Voltage Rating: 600 V to 35 KV
• Conductor Material: Aluminum/Copper
• Conductor Size: 4/0 AWG (Code)
• Barrel Type: Long, Straight
• Pad Size: 0.88 Inch L x 1.21 Inch W x 0.25 Inch Thk
• Number Of Pad Holes: 1
• Catalog Description: ALUMINUM ONE-HOLE LUG, LONG BARREL, BLIND END, MAX 35KV, 4/0 AWG WIRE, 5/16 INCH BOLT SIZE, TIN PLATED, DIE CODE 66H, DIE COLOR CODE WHITE.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Wrought Aluminum Material; White Color; 3.53 Inch Overall Length; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 4/0 AWG (Code) Conductor Size; 5/16 Inch Stud Size; 66 Die Index; 0.88 Inch L X 1.21 Inch W X 0.25 Inch Thk Pad Size; 1 Pad Hole(S); Long, Straight Barrel Type; 601 Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210601472
• SKU Name: t&b 60147
