Product information
Overview
T&B 60542 Copper Tin Plated 2-Way Connector Splice Standard 3/0 Ruby
Product Specifications
- UPC: 78621060542
- Outer Diameter: 0.77 Inch
- Body Material: High Conductivity Electro Tin Plated Wrought Aluminum
- Approval: UL, CSA
- Additional Information: Die Code 60; Temperature Rating 90 Deg C
- Catalog Number: 60542
- Type: 2-Way
- Voltage Rating: 600 Volt to 35 Kilovolt
- Conductor Size: 3/0 AWG
- Conductor Material: Aluminum/Copper
- Color Code: Ruby
- Barrel Type: Standard
- Length: 2.81 Inch
- Catalog Description: TWO-WAY ALUMINUM SPLICE CONNECTOR, WIRE SIZE 3/0, DIE CODE 60, DIE COLOR CODE RUBY
- Category: Large Terminals & Connectors
- Full Technical Description: 2-Way Type; 2.81 Inch; 0.77 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; High Conductivity Electro Tin Plated Wrought Aluminum Body Material; 3/0 AWG Conductor Size; Ruby Color Code; Standard Barrel Type; Die Code 60; Temperature Rating 90 Deg C
- Manufacturer: ABB, Inc. - Thomas & Betts
- Manufacturer Brand: T&B Corp.
- Sub Category: Compression Cable Splice
- Unspsc: 39121449
- UPC 12 Digit: 786210605425
- SKU Name: t&b 60542
