Product information
Overview
T&B 60554 2-Way Aluminum Splice Connector 250 Wire Red
Product Specifications
- UPC: 78621060554
- Outer Diameter: 0.92 Inch
- Body Material: High Conductivity Electro Tin Plated Wrought Aluminum
- Approval: UL, CSA
- Additional Information: Die Code 71; Temperature Rating 90 Deg C
- Catalog Number: 60554
- Type: 2-Way
- Voltage Rating: 600 Volt to 35 Kilovolt
- Conductor Size: 250 KCMIL
- Conductor Material: Aluminum/Copper
- Color Code: Red
- Barrel Type: Standard
- Length: 3.91 Inch
- Catalog Description: TWO-WAY ALUMINUM SPLICE CONNECTOR, WIRE SIZE 250 KCMIL, DIE CODE 71, DIE COLOR CODE RED
- Category: Large Terminals & Connectors
- Full Technical Description: 2-Way Type; 3.91 Inch; 0.92 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; High Conductivity Electro Tin Plated Wrought Aluminum Body Material; 250 kcmil Conductor Size; Red Color Code; Standard Barrel Type; Die Code 71; Temperature Rating 90 Deg C
- Manufacturer: ABB, Inc. - Thomas & Betts
- Manufacturer Brand: T&B Corp.
- Sub Category: Compression Cable Splice
- Unspsc: 39121449
- UPC 12 Digit: 786210605548
- SKU Name: t&b 60554
