T&B 60578 2-Way Aluminum Splice Connector 750 Wire Yellow

Overview

High durability for long-lasting performance, Easy installation and maintenance, Compatible with a wide range of industrial applications

Product Specifications

• UPC: 78621060578
• Outer Diameter: 1.5 INCH
• Body Material: WROUGHT ELECTRO TIN PLATED HIGH CONDUCTIVITY ALUMINUM
• Approval: UL, CSA
• Additional Information: DIE CODE 115; TEMPERATURE RATING 90 DEG C
• Catalog Number: 60578
• Type: 2-WAY
• Voltage Rating: 600 V TO 35 KV
• Conductor Size: 750 KCMIL
• Conductor Material: ALUMINUM/COPPER
• Color Code: YELLOW
• Barrel Type: STANDARD
• Length: 5.69 INCH
• Catalog Description: TWO-WAY ALUMINUM SPLICE CONNECTOR, WIRE SIZE 750 KCMIL, DIE CODE 115, DIE COLOR CODE YELLOW
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 5.69 Inch; 1.5 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; Wrought Electro Tin Plated High Conductivity Aluminum Body Material; 750 kcmil Conductor Size; Yellow Color Code; Standard Barrel Type; Die Code 115; Temperature Rating 90 Deg C
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210605784
• SKU Name: T&B 60578
