T&B 60930 Aluminum Reducing Splice 2Cu 1/0Al Tan

Overview

T&B 60930 Aluminum Reducing Splice 2Cu 1/0Al Tan

Product Specifications

• UPC: 78621060930
• Material: Electrolytic Tin Plated High Conductivity Wrought Aluminum
• Color: Tan
• Approval: UL, CSA
• Additional Information: Die Code 50; Temperature Rating 90 Deg C
• Catalog Number: 60930
• Type: Reducing Connector
• Voltage Rating: 600 V
• Conductor Material: Aluminum/Copper
• Side A Conductor Size: 1/0 AWG (Aluminum)
• Side B Conductor Size: 2 AWG (Copper)
• Outer Diameter: 5/8 Inch
• Length: 2-3/8 Inch
• Catalog Description: ALUMINUM REDUCING SPLICE CONNECTOR FOR COPPER WIRE SIZE 2, ALUMINUM WIRE SIZE 1/0, TIN PLATED, DIE CODE 50, DIE COLOR CODE TAN
• Category: Large Terminals & Connectors
• Full Technical Description: Reducing Connector Type; Electrolytic Tin Plated High Conductivity Wrought Aluminum Material; Tan Color; 2-3/8 Inch; 5/8 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 V Voltage Rating; 2 AWG (Copper) Side B Conductor Size; 1/0 AWG (Aluminum) Side A Conductor Size; Die Code 50; Temperature Rating 90 Deg C
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Reducer
• Unspsc: 39121449
• UPC 12 Digit: 786210609300
• SKU Name: t&b 60930
