T&B 60950 Aluminum Reducing Splice 3/0Cu 250Al Red

Overview

T&B 60950 Aluminum Reducing Splice 3/0Cu 250Al Red

Product Specifications

• UPC: 78621060950
• Length: 4 INCH
• Material: ELECTROLYTIC TIN PLATED HIGH CONDUCTIVITY WROUGHT ALUMINUM
• Color: RED
• Approval: UL, CSA
• Catalog Number: 60950
• Brand Name: Color-Keyed[R]
• Type: REDUCING CONNECTOR
• Voltage Rating: 600 V
• Conductor Material: ALUMINUM/COPPER
• Side A Conductor Size: 250 KCMIL (ALUMINUM)
• Side B Conductor Size: 3/0 AWG (COPPER)
• Outer Diameter: 15/16 INCH
• Catalog Description: ALUMINUM REDUCING SPLICE CONNECTOR FOR COPPER WIRE SIZE 3/0, ALUMINUM WIRE SIZE 250 KCMIL, TIN PLATED, DIE CODE 71, DIE COLOR CODE RED
• Category: Large Terminals & Connectors
• Full Technical Description: Reducing Connector Type; Electrolytic Tin Plated High Conductivity Wrought Aluminum Material; Red Color; 4 Inch; 15/16 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 V Voltage Rating; 3/0 AWG (Copper) Side B Conductor Size; 250 kcmil (Aluminum) Side A Conductor Size; COLOR-KEYED[R] Brand
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Reducer
• Unspsc: 39121449
• UPC 12 Digit: 786210609508
• SKU Name: t&b 60950

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
