T&B 63140 4/0Awg Blue Compression Tap

Overview

T&B 63140 4/0Awg Blue Compression Tap

Product Specifications

• UPC: 78621063140
• Maximum Tap Conductor Size: 2 AWG
• Die Index: D
• Body Material: Wrought High Conductivity Aluminum
• Approval: UL, CSA
• Additional Information: Color Code Blue
• Catalog Number: 63140
• Voltage Rating: 600 V
• Shape: H
• Number Of Taps: 1
• Conductor Material: Aluminum
• Minimum Run Conductor Size: 2/0 AWG
• Maximum Run Conductor Size: 4/0 AWG
• Minimum Tap Conductor Size: 10 AWG
• Catalog Description: ALUMINUM COMPRESSION H-TAP: WIRE RANGE MAIN: 4/0-2/0, BRANCH 2-10, LENGTH 1-1/2 INCHES, DIE CODE D, DIE COLOR CODE BLUE
• Category: Large Terminals & Connectors
• Full Technical Description: 2/0 AWG min. Run Conductor Size; 4/0 AWG Max. Run Conductor Size; 10 AWG min. Tap Conductor Size; 2 AWG Max. Tap Conductor Size; H Shape; Aluminum Conductor Material; UL, CSA Approval; 600 V Voltage Rating; Wrought High Conductivity Aluminum Body Material; D Die Index; 1 Tap(S); Color Code Blue
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Tap
• Unspsc: 39121428
• UPC 12 Digit: 786210631400
• SKU Name: t&b 63140
