T&B 63160 500Mcm Red Compression Tap

Overview

T&B 63160 500Mcm Red Compression Tap

Product Specifications

• UPC: 78621063160
• Maximum Tap Conductor Size: 2 AWG (Side Tap), 4/0 AWG (Branch)
• Die Index: N
• Body Material: Wrought High Conductivity Aluminum
• Approval: UL, CSA
• Additional Information: Color Code Red
• Catalog Number: 63160
• Voltage Rating: 600 V
• Shape: H
• Number Of Taps: 2
• Conductor Material: Aluminum
• Minimum Run Conductor Size: 4/0 AWG
• Maximum Run Conductor Size: 500 KCMIL
• Minimum Tap Conductor Size: 6 AWG (Side Tap), 2 AWG (Branch)
• Catalog Description: ALUMINUM COMPRESSION H-TAP: WIRE RANGE MAIN: 500-4/0, BRANCH 4/0-2, SIDE TAP 2-6, LENGTH 2-3/4 INCHES, DIE CODE N, DIE COLOR CODE RED
• Category: Large Terminals & Connectors
• Full Technical Description: 4/0 AWG min. Run Conductor Size; 500 kcmil Max. Run Conductor Size; 6 AWG (Side Tap), 2 AWG (Branch) min. Tap Conductor Size; 2 AWG (Side Tap), 4/0 AWG (Branch) Max. Tap Conductor Size; H Shape; Aluminum Conductor Material; UL, CSA Approval; 600 V Voltage Rating; Wrought High Conductivity Aluminum Body Material; N Die Index; 2 Tap(S); Color Code Red
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Tap
• Unspsc: 39121428
• UPC 12 Digit: 786210631608
• SKU Name: t&b 63160
