T&B 71015 Locktite Copper Cone Screw Lug 1-250

Overview

T&B 71015 Locktite Copper Cone Screw Lug 1-250

Product Specifications

• UPC: 78621071015
• Material: Copper
• Number Of Pad Holes: 1
• Pad Size: 29/32 Inch Length x 1 Inch Width x 7/32 Inch Thickness
• Stud Size: 3/8 Inch
• Overall Length: 2-1/32 Inch
• Approval: UL, CSA
• Catalog Number: 71015
• Brand Name: LOCKTITE[R]
• Type: Cone Screw
• Number Of Conductors: 1
• Minimum Conductor Size: 1 AWG
• Maximum Conductor Size: 250 KCMIL
• Conductor Material: Copper
• Pad Type: Straight
• Catalog Description: LOCKTITE COPPER CONE SCREW LUG FOR CONDUCTOR RANGE 1-250, 3/8 INCH BOLT HOLE, WRENCH TORQUE 250 IN/LBS
• Category: Large Terminals & Connectors
• Full Technical Description: Cone Screw Type; Copper Material; 2-1/32 Inch Overall Length; 1 AWG min. Conductor Size; 250 kcmil Max. Conductor Size; Copper Conductor Material; UL, CSA Approval; 1 Conductor(S); 3/8 Inch Stud Size; 29/32 Inch Length X 1 Inch Width X 7/32 Inch Thickness Pad Size; 1 Pad Hole(S); Straight Pad Type
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Mechanical Cable Lug
• Unspsc: 39121408
• UPC 12 Digit: 786210710150
• SKU Name: t&b 71015

Resources

• Manufacturer Spec Sheet
