T&B GR34-202 Fig 8 Connector 3/4" Ground Rod 2-2/0 Awg

Overview

T&B GR34-202 Fig 8 Connector 3/4" Ground Rod 2-2/0 Awg

Product Specifications

• UPC: 78621018590
• Application: CABLE TO GROUND ROD
• Approval: UL, CSA
• Additional Information: NUMBER OF CONTACTS 2
• Catalog Number: GR34-202
• Brand Name: Color-Keyed.
• Type: TAP
• Width: 7/8 INCH
• Height: 2-3/16 INCH
• Material: COPPER
• Conductor Size: 2 TO 2/0 AWG
• Grounding Rod Size: 3/4 INCH
• Catalog Description: E-Z-GROUND FIGURE 8 COPPER COMPRESSION GROUND ROD TAP CONNECTOR FOR CABLE RANGE 2 AWG - 2/0 AWG, GROUND ROD 3/4 INCH, HEIGHT 2-3/16 INCHES
• Category: Large Terminals & Connectors
• Full Technical Description: Tap Type; Copper Material; 7/8 Inch; 2-3/16 Inch; UL, CSA Approval; Cable to Ground Rod Application; 2 to 2/0 AWG Conductor Size; 3/4 Inch Grounding Rod Size; Color-Keyed. Brand; Number of Contacts 2
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Grounding Connector
• Unspsc: 39121613
• UPC 12 Digit: 786210185903
• SKU Name: t&b gr34202
