T&B H300GRA-TB Bullet Hub 3" W/Ground Locknut

Overview

High load capacity of up to 1,500 lbs, Corrosion-resistant finish for longevity, Easy installation with pre-drilled mounting holes, Versatile design suitable for multiple applications

Product Specifications

• UPC: 78621091482
• Approval: UL, CSA
• Used On: Rigid Conduit/IMC
• Additional Information: Maximum Panel Thickness 1/4 Inch; Temperature Rating 105 Deg C
• Catalog Number: H300GRA-TB
• Type: Bulkhead, Tapered Female Threaded
• Throat Type: Thermoplastic Insulated
• Trade Size: 3 Inch
• Size: 4-3/8 Inch Dia x 2-7/16 Inch L
• Constructional Feature: Hazardous Location
• Ground Type: Locknut Bonding/Grounding Screw
• Material: Copper Free Aluminum Locknut/Hub, Nitrile Sealing Ring
• Catalog Description: 3 INCH ALUMINUM, GROUNDING HUB WITH THERMOPLASTIC INSULATING THROAT, SEALING RING NITRILE (BUNA-N) FOR USE WITH RIGID/IMC CONDUIT
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: Bulkhead, Tapered Female Threaded Type; Copper Free Aluminum Locknut/Hub, Nitrile Sealing Ring Material; 4-3/8 Inch Dia X 2-7/16 Inch L Size; Rigid Conduit/Imc Used on; UL, CSA Approval; Locknut Bonding/Grounding Screw; 3 Inch Trade Size; Hazardous Location; Thermoplastic Insulated Throat Type; BULLET[R] Brand; Maximum Panel Thickness 1/4 Inch; Temperature Rating 105 Deg C
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Rigid/EMT Conduit Hub
• Unspsc: 39131707
• UPC 12 Digit: 786210914824
• SKU Name: H300GRATB
