T&B RAT863 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Overview

T&B RAT863 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Product Specifications

• UPC: 78621083906
• Temperature Rating: 150 DEG C
• Standard Package: 1000
• Approval: UL 486-A, CSA 22.2
• Additional Information: DIMENSION 0.84 INCH LENGTH X 0.31 INCH WIDTH X 0.03 INCH THICK; FINISH ELECTROPLATED TIN
• Catalog Number: RAT863
• Brand Name: Sta-Kon.
• Model: RAT
• Type: STANDARD
• Minimum Conductor Size: 22 AWG
• Maximum Conductor Size: 18 AWG
• Insulation Type: TEFZEL. INSULATED
• Stud Size: #8
• Catalog Description: FLUOROPOLYMER INSULATED RING TERMINAL FOR WIRE RANGE 22-18 STUD SIZE #8, CLEAR/RED STRIPE
• Category: Small Terminals & Connectors
• Full Technical Description: Standard Type; 22 AWG min. Conductor Size; 18 AWG Max. Conductor Size; UL 486-A, CSA 22.2 Approval; 150 Deg C Temperature Rating; 1000 Standard Package; #8 Stud Size; Tefzel. Insulated Insulation Type; Sta-Kon. Brand; Dimension 0.84 Inch Length X 0.31 Inch Width X 0.03 Inch Thick; Finish Electroplated Tin; RAT Model
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Ring Lug
• Unspsc: 39121432
• UPC 12 Digit: 786210839066
• SKU Name: t&b rat863
