T&B RB14-14F Insulated Nylon Fork Terminal 18-14 Blt1/4 Blue

Overview

T&B RB14-14F Insulated Nylon Fork Terminal 18-14 Blt1/4 Blue

Product Specifications

• UPC: 78621080418
• Temperature Rating: 105 Deg C
• Standard Package: 500 per Outer Pack
• Approval: UL, CSA
• Additional Information: Voltage Rating 600 Volt; Overall Dimension 0.95 Inch Length x 0.44 Inch Width; Material Copper; Finish Electro Tin Plated
• Catalog Number: RB14-14F
• Brand Name: Sta-Kon
• Type: Standard
• Minimum Conductor Size: 18 AWG
• Maximum Conductor Size: 14 AWG
• Color: Blue
• Insulation Type: Nylon Insulated
• Stud Size: 1/4 Inch
• Catalog Description: NYLON INSULATED FORK TERMINAL, LENGTH .95 INCHES, WIDTH .44 INCHES, MAXIMUM INSULATION .190, BOLT HOLE 1/4 INCH, WIRE RANGE #18-#14 AWG, COLOR BLUE, COPPER, TIN PLATED, 100 PACK
• Category: Small Terminals & Connectors
• Full Technical Description: Standard Type; Blue Color; 18 AWG min. Conductor Size; 14 AWG Max. Conductor Size; UL, CSA Approval; 105 Deg C Temperature Rating; 500 Per Outer Pack Standard Package; 1/4 Inch Stud Size; Nylon Insulated Insulation Type; Voltage Rating 600 Volt; Overall Dimension 0.95 Inch Length X 0.44 Inch Width; Material Copper; Finish Electro Tin Plated
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Fork Lug
• Unspsc: 39121432
• UPC 12 Digit: 786210804187
• SKU Name: t&b rb1414f
