Product information
Overview
T&B RB14-47PT Insulated Nylon Pin Terminal 12-10 Awg Blue
Product Specifications
- UPC: 78621092181
- Approval: UL, CSA
- Additional Information: Voltage Rating 300 Volt; Length 0.87 Inch; Pin Size 0.075 Inch Diameter x 0.39 Inch Length; Material Copper; Finish Electro Tin Plated
- Catalog Number: RB14-47PT
- Brand Name: Sta-Kon
- Conductor Size: 16 to 14 AWG
- Color: Blue
- Insulation Type: Nylon Insulated
- Temperature Rating: 105 Deg C
- Standard Package: 500 per Outer Pack
- Application: European/Metric Style Terminal Block
- Catalog Description: NYLON INSULATED PIN TERMINAL, LENGTH .87 INCHES, PIN LENGTH .390 INCHES, DIAMETER .075 INCHES, WIRE RANGE #16-#14 AWG, COLOR BLUE, COPPER, TIN PLATED
- Category: Small Terminals & Connectors
- Full Technical Description: Blue Color; UL, CSA Approval; European/Metric Style Terminal Block Application; 105 Deg C Temperature Rating; 500 Per Outer Pack Standard Package; 16 to 14 AWG Conductor Size; Nylon Insulated Insulation Type; Voltage Rating 300 Volt; Length 0.87 Inch; Pin Size 0.075 Inch Diameter X 0.39 Inch Length; Material Copper; Finish Electro Tin Plated
- Made In Usa: Yes
- Manufacturer: ABB, Inc. - Thomas & Betts
- Manufacturer Brand: T&B Corp.
- Sub Category: Pin Terminal Lug
- Unspsc: 39121432
- UPC 12 Digit: 786210921815
- SKU Name: t&b rb1447pt
