T&B RCC21 Insulated Nylon Butt Splice 12-10 Awg

Overview

T&B RCC21 Insulated Nylon Butt Splice 12-10 Awg

Product Specifications

• UPC: 78621082050
• Insulation Type: Nylon Insulated
• Color: Yellow
• Material: Electro Tin Plated Copper
• Temperature Rating: 105 Deg C
• Standard Package: 5000 per Outer Pack
• Approval: UL 94, CSA
• Additional Information: Applicable Standard MIL-T-7928
• Catalog Number: RCC21
• Brand Name: Sta-Kon
• Type: Butt
• Voltage Rating: 600 Volt
• Length: 1.26 Inch
• Barrel Outer Diameter: 0.28 Inch
• Maximum Insulation Diameter: 0.21 Inch
• Conductor Size: 12 to 10 AWG
• Catalog Description: NYLON INSULATED BUTT SPLICE, LENGTH 1.26 INCHES, WIDTH .28 INCHES, MAXIMUM INSULATION DIAMETER .210, WIRE RANGE #12-#10 AWG, COLOR YELLOW, COPPER, TIN PLATED, 500 PACK
• Category: Small Terminals & Connectors
• Full Technical Description: Butt Type; Electro Tin Plated Copper Material; Yellow Color; 1.26 Inch; 0.21 Inch Max. Insulation Diameter; UL 94, CSA Approval; 600 Volt Voltage Rating; 105 Deg C Temperature Rating; 5000 Per Outer Pack Standard Package; 12 to 10 AWG Conductor Size; Nylon Insulated Insulation Type; 0.28 Inch Barrel Outer Diameter; Applicable Standard mil-T-7928
• Made In Usa: Yes
• Manufacturer: THOMAS & BETTS
• Manufacturer Brand: T&B Corp.
• Sub Category: Splice Connector
• Unspsc: 39121449
• UPC 12 Digit: 786210820507
• SKU Name: t&b rcc21
