T&B RCT333 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Overview

T&B RCT333 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Product Specifications

• UPC: 78621083912
• Temperature Rating: 150 DEG C
• Standard Package: 500
• Approval: UL 486-A, CSA 22.2
• Additional Information: DIMENSION 1 INCH LENGTH X 0.37 INCH WIDTH X 0.04 INCH THICK; FINISH ELECTROPLATED TIN
• Catalog Number: RCT333
• Brand Name: Sta-Kon.
• Model: RCT
• Type: STANDARD
• Minimum Conductor Size: 12 AWG
• Maximum Conductor Size: 10 AWG
• Insulation Type: TEFZEL. INSULATED
• Stud Size: #6
• Catalog Description: FLUOROPOLYMER INSULATED RING TERMINAL FOR WIRE RANGE 12-10 STUD SIZE #6, CLEAR/YELLOW STRIPE
• Category: Small Terminals & Connectors
• Full Technical Description: Standard Type; 12 AWG min. Conductor Size; 10 AWG Max. Conductor Size; UL 486-A, CSA 22.2 Approval; 150 Deg C Temperature Rating; 500 Standard Package; #6 Stud Size; Tefzel. Insulated Insulation Type; Sta-Kon. Brand; Dimension 1 Inch Length X 0.37 Inch Width X 0.04 Inch Thick; Finish Electroplated Tin; RCT Model
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Ring Lug
• Unspsc: 39121432
• UPC 12 Digit: 786210839127
• SKU Name: t&b rct333
