T&B RCT713 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Overview

T&B RCT713 Insulated Fluoropolymer Ring Terminal 22-18, 1/4, Copper Lug

Product Specifications

• UPC: 78621083915
• Standard Package: 500 per Pack
• Approval: UL 486A/B, CSA 22.2
• Additional Information: Size 1.11 Inch Length x 0.52 Inch Width; Maximum Insulation 0.21 Inch; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper
• Catalog Number: RCT713
• Brand Name: Tefzel[R]
• Minimum Conductor Size: 12 AWG
• Maximum Conductor Size: 10 AWG
• Color: Clear/Yellow Stripe
• Insulation Type: Fluoropolymer Insulated, Funnel Entry
• Stud Size: 1/4 Inch
• Temperature Rating: 150 Deg C
• Catalog Description: FLUOROPOLYMER INSULATED RING TERMINAL FOR WIRE RANGE 12-10 STUD SIZE 1/4, CLEAR/YELLOW STRIPE
• Category: Small Terminals & Connectors
• Full Technical Description: Clear/Yellow Stripe Color; 12 AWG min. Conductor Size; 10 AWG Max. Conductor Size; UL 486A/B, CSA 22.2 Approval; 150 Deg C Temperature Rating; 500 Per Pack Standard Package; 1/4 Inch Stud Size; Fluoropolymer Insulated, Funnel Entry Insulation Type; TEFZEL[R] Brand; Size 1.11 Inch Length X 0.52 Inch Width; Maximum Insulation 0.21 Inch; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Ring Lug
• Unspsc: 39121432
• UPC 12 Digit: 786210839158
• SKU Name: t&b rct713
