T&B REE28 Insulated Nylon Butt Spl 6 Len 1.85 Dia

Overview

T&B REE28 Insulated Nylon Butt Spl 6 Len 1.85 Dia

Product Specifications

• UPC: 78621089450
• Insulation Type: Nylon Insulated
• Color: Blue
• Material: Electro Tin Plated Copper
• Temperature Rating: 105 Deg C
• Standard Package: 200
• Approval: UL 94, CSA
• Additional Information: Applicable Standard MIL-T-7928
• Catalog Number: REE28
• Model: REE
• Type: Butt
• Voltage Rating: 600 V
• Length: 1.85 Inch
• Barrel Outer Diameter: 0.45 Inch
• Maximum Insulation Diameter: 0.42 Inch
• Conductor Size: 6 AWG
• Catalog Description: NYLON INSULATED BUTT SPLICE, LENGTH 1.85 INCHES, WIDTH .45 INCHES, MAXIMUM INSULATION DIAMETER .420, WIRE RANGE #6, COLOR BLUE, COPPER, TIN PLATED, 200 PACK
• Category: Large Terminals & Connectors
• Full Technical Description: Butt Type; Electro Tin Plated Copper Material; Blue Color; 1.85 Inch; 0.42 Inch Max. Insulation Diameter; UL 94, CSA Approval; 600 V Voltage Rating; 105 Deg C Temperature Rating; 200 Standard Package; 6 AWG Conductor Size; Nylon Insulated Insulation Type; 0.45 Inch Barrel Outer Diameter; Applicable Standard mil-T-7928; REE Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Splice Connector
• Unspsc: 39121449
• UPC 12 Digit: 786210894508
• SKU Name: t&b ree28

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
