Overview

Unistrut P1047-EG 5-Hole U Support

Product Specifications

• Brand Name: Unistrut
• Special Features: Part of Complete System
• Sub Brand: Metal Framing Components
• Type: An L-shaped metal bracket.
• Catalog Description: STRUT FITTING, 5-3/8"X 1-7/8"X 1-5/8", EG
• Category: Channel & Strut Fittings
• Full Technical Description: U-Fitting Type; ASTM A1011/A36/A575/A576/A635/B633 Grade SS 33 Steel Material; 5-3/8 Inch Length X 1-21/32 Inch Width X 1-5/8 Inch Height Size; Electrogalvanized Finish; Channel Used on; 1-5/8 Inch Channel Width; UL, CSA Applicable Standard; 1/4 Inch Thickness; Hot Rolled Pickled and Oiled Process; 0.88 Pound Weight; 5 Hole(S); 9/16 Inch Diameter Hole Size; 1-5/8 Inch Channel Depth; 1-21/32 Inch Width X 1-5/8 Inch Height Saddle Size; Hole Spacing Size 13/16 Inch (From End)
• Made In Usa: Yes
• Manufacturer: Unistrut Corp.
• Manufacturer Brand: Unistrut Corp.
• Sub Category: Channel/Strut U Fitting
• Unspsc: 31162502
• UPC 12 Digit: 786364104713
• SKU Name: unistr p1047eg

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
