Unistrut P1063-HG Flat Plate Fitting

Product Specifications

• Brand Name: Unistrut
• Depth: 1-5/8 in
• Finish: Electrogalvanizing
• Fits Bolt Sizes: 3/8 IN
• Material: ASTM A575, A576, A635 Or A36, ASTM A1011 SS GR 33 Steel
• Steel Thickness: 1/4 IN
• Thickness: 1-1/4 IN
• Type: One Hole Washer
• Width: 1.625 in
• Catalog Description: STRUT FITTING, 3/8", 1-5/8"X 1/4"X 1-5/8", HG
• Category: Channel & Strut Fittings
• Full Technical Description: Square Type; ASTM A36/A575/A576/A635/A1011/A123/A153 Steel Material; Hot Dip Galvanized Finish; 1-5/8 Inch; 1-5/8 Inch; UL, CSA Applicable Standard; 1/4 Inch Thickness; Hot Rolled Pickled and Oiled Process; 19.1 Pound Per 100 Weight; 7/16 Inch Diameter Hole Size; 3/8 Inch-16 TPI Bolt/Rod Size; Hole Spacing Size 13/16 Inch (From End); Used on 1-5/8 Inch Width Channel
• Made In Usa: Yes
• Manufacturer: Unistrut Corp.
• Manufacturer Brand: Unistrut Corp.
• Sub Category: Channel Washer
• Unspsc: 31161812
• UPC 12 Digit: 786364016542
• SKU Name: unistr p1063hg
