Burndy YAV10M8 10Mm Copper Metric 1-Hole M8

Overview

Burndy YAV10M8 10Mm Copper Metric 1-Hole M8

Product Specifications

• UPC: 78181026494
• Pad Size: 13.2 MM W X 1.5 MM THK
• Number Of Pad Holes: 1
• Stud Size: M8
• Die Index: 49
• Material: ELECTRO TIN PLATED COPPER
• Overall Length: 33 MM
• Additional Information: ROHS COMPATIBLE; CABLE ENTRY TYPE CHAMFERED; WIRE STRIP LENGTH 11 MM
• Catalog Number: YAV10M8
• Brand Name: HYLUG[T], BURNDY[R]
• Model: YAV-M
• Voltage Rating: 600 V TO 35 KV
• Conductor Material: COPPER
• Conductor Size: 10 SQ MM
• Barrel Type: STANDARD, STRAIGHT
• Barrel Length: 11.2 MM
• Catalog Description: HYLUG COMPRESSION TERMINAL FOR COPPER; ACCOMMODATES: #8 AWG; STUD: .33"; LENGTH: 1.29"; WIRE STRIP LENGTH: 11MM.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Copper Material; 33 mm Overall Length; 11.2 mm Barrel Length; Copper Conductor Material; 600 V to 35 kV Voltage Rating; 10 Sq mm Conductor Size; M8 Stud Size; 49 Die Index; 13.2 mm W X 1.5 mm Thk Pad Size; 1 Pad Hole(S); Standard, Straight Barrel Type; HYLUG[T], BURNDY[R] Brand; RoHS Compatible; Cable Entry Type Chamfered; Wire Strip Length 11 mm; YAV-M Model
• Made In Usa: Yes
• Manufacturer: BURNDY PRODUCTS
• Manufacturer Brand: Burndy Products
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810264942
• SKU Name: yav10m8 burndy
