Burndy YAV25M10 Copper Tubular Terminal

Product Specifications

• Catalog Description: NON INSULATED CU TUBULAR TERMINALS, METRIC, 1 HOLE/W/INSP W, 25 MMCLASS 2, 3/8" STUD, TIN - ELECTRO PLATED, 9 INDEX,TONGUE THICKNESS :2.0.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Copper Material; 41.4 mm Overall Length; 12.7 mm Barrel Length; Copper Conductor Material; 600 V to 35 kV Voltage Rating; 25 Sq mm Conductor Size; M10 Stud Size; 9 Die Index; 14.7 mm W X 2 mm Thk Pad Size; 1 Pad Hole(S); Standard, Straight Barrel Type; HYLUG[T], BURNDY[R] Brand; RoHS Compatible; Cable Entry Type Chamfered; Wire Strip Length 13 mm; YAV-M Model
• Made In Usa: Yes
• Manufacturer: BURNDY PRODUCTS
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810373330
• SKU Name: yav25m10 burndy
