Ilsco CSWD-2/0-12-134 2-Hole Lug

Overview

Ilsco CSWD-2/0-12-134 2-Hole Lug

Product Specifications

• UPC: 78366963817
• Pad Size: 3 Inch L x 0.811 Inch W x 0.125 Inch Thk
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1-3/4 Inch
• Stud Size: 1/2 Inch
• Color: Black
• Die Index: I-45
• Material: Seamless Electro-Tin Plated Copper
• Overall Length: 4.146 Inch
• Approval: UL 453G, UL 467, UL 486A/B, CSA
• Additional Information: ROHS Compatible; Size 0.437 Inch ID x 0.562 Inch OD; Barrel Type Chamfered Entry; Temperature Rating 90 Deg C
• Catalog Number: CSWD-2/0-12-134
• Brand Name: SureCrimp[R]
• Model: CSWD
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 2/0 AWG
• Barrel Type: Standard
• Barrel Length: 0.75 Inch
• Catalog Description: SURECRIMP COPPER COMPRESSION LUG, CONDUCTOR SIZE 2/0, 2 HOLES, 1/2IN BOLT SIZE, 1-3/4IN HOLE SPACING, STANDARD BARREL, SIGHT WINDOW, TIN PLATED, UL, CSA
• Category: Large Terminals & Connectors
• Full Technical Description: Seamless Electro-Tin Plated Copper Material; Black Color; 4.146 Inch Overall Length; 0.75 Inch Barrel Length; Copper Conductor Material; UL 453G, UL 467, UL 486A/B, CSA Approval; 35 kV Voltage Rating; 2/0 AWG Conductor Size; 1/2 Inch Stud Size; I-45 Die Index; 3 Inch L X 0.811 Inch W X 0.125 Inch Thk Pad Size; 2 Pad Hole(S); 1-3/4 Inch Pad Hole Spacing; Standard Barrel Type; Surecrimp [R] Brand; RoHS Compatible; Size 0.437 Inch ID X 0.562 Inch OD; Barrel Type Chamfered Entry; Temperature Rating 90 Deg C; CSWD Model
• Made In Usa: Yes
• Manufacturer: ILSCO CORP
• Manufacturer Brand: ILSCO Corp.
• Proposition 65 Warning (Ca): This product is in compliance with Prop65; it is not known to contain any chemicals associated with this regulation
• Sub Category: Compression Cable Lug
• Unspsc: 39121448
• UPC 12 Digit: 783669638172
• SKU Name: ilsco cswd2/012134
