3M FP301-1-50'-Blue-Spool Heat Shrink Thin-Wall Tubing, Blue, 50 ft

Overview

3M FP301-1-50'-Blue-Spool Heat Shrink Thin-Wall Tubing, Blue, 50 ft

Product Specifications

• UPC: 05113535601
• Brand: 3M
• 3M Number: FP301-1-50'-Blue-Spool
• Part Number: 35601
• Type: Heat Shrink Thin-Wall Tubing
• Material: Polyolefin
• Color: Blue
• Shrink Ratio: 2:1
• Inner Diameter Before Shrinking: 1 in
• Inner Diameter After Shrinking: 0.5 in
• Wall Thickness After Shrinking: 0.035 in
• Overall Length: 50 ft
• Dielectric Strength: 900 V/mil
• Tensile Strength: 2400 psi
• Shrink Temperature: +212°F
• Maximum Operating Temperature: +275°F
• Package Quantity: 50 ft per Spool; 150 ft per Carton
• Kit Type: 0.5
• Standards Met: AMS 3636; AMS 3637; AMS DTL-23053/5 Class 1; AMS DTL-23053/5 Class 2; CSA LR38227; UL E39100
• Application: Electrical Insulation, Wire Identification, Cable Protection, Strain Relief, Harness Bundling and General-Purpose Heat Shrink Applications
• Category: Heat Shrink Tubing
• Full Technical Description: 3M FP301 Blue Polyolefin Heat Shrink Thin-Wall Tubing; 1 Inch Supplied Inner Diameter; Shrinks to 0.5 Inch Inner Diameter; 50 ft Overall Length; 2:1 Shrink Ratio; 0.035 Inch Wall Thickness After Shrinking; 900 V/mil Dielectric Strength; 2400 psi Tensile Strength; Shrink Temperature +212°F; Maximum Operating Temperature +275°F; Meets AMS 3636, AMS 3637, AMS DTL-23053/5 Class 1 and 2, CSA LR38227 and UL E39100 Standards
• Manufacturer Brand: 3M
• Sub Category: Thin-Wall Heat Shrink Tubing
• SKU Name: 3m fp301 1 blue thin wall heat shrink tubing
