Appleton 470FSA 1-1/4" Aluminum Conduit Body Cover

Overview

Appleton 470FSA 1-1/4" Aluminum Conduit Body Cover

Product Specifications

• UPC: 78138160129
• Catalog Number: 470FSA
• Brand Name: Wedge-Lok[T], Appleton.
• Trade Size: 1-1/4 INCH
• Form Type: FORM 7
• Material: EPOXY POWDER COATED CAST COPPER FREE ALUMINUM
• Installation: BLANK, SCREW
• Catalog Description: FM7 WEDGE-LOK BLANK CLIP COVER WITH SCREW, HUB SIZE: 1-1/4 IN, FORM: 7, MOUNTING: SCREW-IN, MATERIAL: CAST ALUMINUM, FINISH: EPOXY POWDER COAT, STANDARD: UL 514A, UL 514B, UL FILE NUMBER E2527, CSA C22.2 NO. 18.3, CSA 065183, NEMA FB-1, FO
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Clip Type; Zinc Electroplated Copper-Free Cast Aluminum Material; UL 514A/B, CSA C22.2 Approval; 1-1/4 Inch Trade Size; Form 7 Form Type; FM7[TM], Wedge-LOK[TM] Brand; Enclosure Rating Class I Div 2, NEMA 3R; Operating Temperature Rating -65 to 302 Deg F; Includes Stainless Steel Screw; Used on Imc/Rigid Conduit; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body Cover
• Unspsc: 39131708
• UPC 12 Digit: 781381601290
• SKU Name: app 470fsa

Resources

• Manufacturer Spec Sheet
