Appleton EFHCA-7575 3/4" Fixture Hanger

Overview

Appleton EFHCA-7575 3/4" Fixture Hanger

Product Specifications

• UPC: 78138127700
• Material: Zinc Electroplated Dichromate Epoxy Powder Coated Malleable Iron
• Approval: UL, CSA
• Additional Information: Enclosure Class I, Group A B C D, Class II Group E F G, Class III; Application Moisture, Dust and Corrosive Atmospheres are Present
• Catalog Number: EFHCA-7575
• Brand Name: Unilet[R]
• Model: EFHCA
• Fixture Type: HID, Fluorescent, Incandescent
• Fixture Stem Size: 3/4 Inch
• Conduit Size: 3/4 Inch
• Number Of Hubs: 2
• Hub Location: Side, Feed Through
• Catalog Description: UNILETS FIXTURE HANGER, SIZE: 3/4 IN FIXTURE STEM, MATERIAL: MALLEABLE IRON, LAMP TYPE: HID, INCANDESCENT AND FLUORESCENT, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), STANDARD: CLASS I, GROUPS A, B, C AND D, CLASS II, GROUPS E, F AND G, CLASS III, FOR USE WITH THREADED METAL CONDUIT
• Category: Lighting Accessories
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Epoxy Powder Coated Copper-Free Aluminum (Cover) Material; 2 Hub(S); UL 1203, CSA Approval; 350 Pound Capacity; 3/4 Inch Conduit Size; Side, Feed-Through Hub Location; HID, Fluorescent, Incandescent Fixture Type; 3/4 Inch Fixture Stem Size; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Capacity 13.8 Cubic Inch; Enclosure Rating Class I Div 1 and 2 Group A B C D, Class II Div 1 and 2 Group E F G, Class III; Application Hazardous Location; Used With Threaded Metal Conduit; Applicable Standard Nec/Cec; EFHCA Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pendant Fixture Conduit Body Hanger
• Unspsc: 39111817
• UPC 12 Digit: 781381277006
• SKU Name: app efhca7575

Resources

• Manufacturer Spec Sheet
