Appleton KPWB75 3/4" Wall Bracket

Overview

Appleton KPWB75 3/4" Wall Bracket

Product Specifications

• UPC: 78138154843
• Finish: Baked Gray Epoxy Clad
• Enclosure: Class I Div 2 Group A B C D, Class I Zone 2 AEx nA IIC, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3R/4/4X/IP66
• Approval: UL 50/844/1598/1598A/8750, CSA C22.2
• Additional Information: Voltage Rating 120 to 277 Volt AC at 50/60 Hertz; Applicable Standard ATEX/IECEx
• Catalog Number: KPWB75
• Brand Name: Mercmaster[TM]
• Type: Wall
• Constructional Feature: Explosionproof, Wet Location
• Number Of Hubs: 5
• Number Of Plugs: 4
• Hub Size: 3/4 Inch
• Material: Copper-Free Cast Aluminum
• Catalog Description: MOUNTING HOOD, SIZE: 3/4 IN HUB, MATERIAL: CAST COPPERFREE (4/10 OF 1 PCT MAXIMUM) ALUMINUM, LAMP TYPE: HIGH PRESSURE SODIUM AND PULSE START METAL HALIDE, MOUNTING: WALL, FINISH: BAKED GRAY EPOXY-CLAD, FOR MERCMASTER III LOW PROFILE LUMINA
• Category: Hid Hazardous Location Lighting
• Full Technical Description: Wall Type; Copper-Free Cast Aluminum Material; Electrostatically Applied Baked Gray Epoxy Clad Finish; 3/4 Inch Threaded Hub Size; 5 Hub(S); UL 50/844/1598/1598A/8750, CSA (Canada and Us), CSA C22.2 Approval; Class I Div 2 Group A B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class I Zone 2 Group Iic, Class III, NEMA 3R/4/4X, IP66/67 Enclosure; 4 (Close-Up) Plug(S); Used on Mercmaster LED Luminaire; Application Pulp/Paper Mill, Processing/Chemical Plant, Oil Refinery, Foundry, Manufacturing Plant, Storage Area, Waste/Sewage Treatment, Parking Garage; Applicable Standard Nec/Cec, Ansi/Iec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof HID Fixture Mounting Hood
• Unspsc: 39111817
• UPC 12 Digit: 781381548434
• SKU Name: app kpwb75

Resources

• Manufacturer Spec Sheet
