Blackburn KL31-1 1/0Awg Sleeve

Overview

Blackburn KL31-1 1/0Awg Sleeve

Product Specifications

• Brand Name: Blackburn
• Special Features: Splices large conductors required for commercial service, use as low cost reducing sleeve. All sizes can be installed with popular mechanical and hydraulic tools. Center stop assures proper conductor positioning. Quick identifications with color-coded foil caps.
• Standard: Passes the requirements of ANSI C119.4
• Type: Compression Splice Service Entrance
• Conductor Range: End A: #1 STR ; 1/0 COMPT ; 1/0 SOL. End B: #1 STR ; 1/0 COMPT ; 1/0 SOL
• Connection: Compression
• Environmental Conditions: All Seasons / Conditions
• Insulation: None
• Material: Aluminum
• Mounting: None
• Number Of Conductors: 2
• Size: 3-1/2 Inch
• Catalog Description: ALUMINUM 3-1/2 INCH SERVICE ENTRANCE COMPRESSION SPLICE FOR WIRE RANGE - END A: 2 ASCR, 1 SOL. AL., 1 STR., 1/0 STR. COMPACT, RED, END B: 1 SOL. AL., 1 STR., 1/0 STR. COMPACT, RED, DIE: 840. FOR AL TO AL AND AL TO CU CONDUCTORS.
• Category: Service Entrance Cable Fittings
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Service Entrance Sleeve
• Unspsc: 39121449
• UPC 12 Digit: 783786047536
• SKU Name: blkbrn kl311

Resources

• Manufacturer Spec Sheet
