Crouse-Hinds E1049-1810X-R Yellow 2-Hole Male Receptacle

Overview

Crouse-Hinds E1049-1810X-R Yellow 2-Hole Male Receptacle

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES ROUGHNECK E1049 RECEPTACLE ASSEMBLY, UP TO 1135A CONTINUOUS, 313-777 KCMIL, RED, MALE, ROTATING, RUBBER, DOUBLE HOLE BUS BAR, 1000 VAC/DC
• Full Technical Description: 45 Deg Male Type; 3.5 Inch Dia Size; Double Hole Bus Bar Connection Type; 313 to 777 kcmil Cable Size; UL (Canada and Us) Approval; Oil and Drilling Application; 1000 VAC/VDC Voltage Rating; NEMA 3 Enclosure; 1135 Ampere (Continuous) Current Rating; Roughneck Construction; 1 Pole(S); Silver Plated Copper Contact Material; Rubber Insulator Material; Red Insulator Color; ROUGHNECK[TM] Brand; Material Epoxy Powder Coated Aluminum Alloy (Receptacle Shell), Stainless Steel (Hardware); Includes Insulator, Receptacle Housing, Gasket, Dust Cover; Temperature Rating -40 to 125 Deg C; E1049 Model
• Manufacturer: EATON CROUSE-HINDS MOLDED PRODUCTS
• Sub Category: Cam Type Receptacle
• Unspsc: 39121406
• UPC 12 Digit: 662275878236
• SKU Name: camlok e10491810xr
