Blackburn CTL10-2516 Copper Test Point 2-Hole Lug Short Barrel 1/0 5/16 Pink

Overview

Blackburn CTL10-2516 Copper Test Point 2-Hole Lug Short Barrel 1/0 5/16 Pink

Product Specifications

• UPC: 78378613123
• Number Of Pad Holes: 2
• Pad Hole Spacing: 7/8 Inch
• Stud Size: 5/16 Inch
• Color: Pink
• Die Index: 42H
• Material: Tin Plated Seamless Copper
• Overall Length: 2-11/16 Inch
• Approval: UL, CSA
• Additional Information: Application Regular Duty, Conned Area
• Catalog Number: CTL10-2516
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 1/0 AWG Stranded
• Barrel Type: Short, Straight
• Barrel Length: 11/16 Inch
• Pad Size: 1-3/4 Inch L x 3/4 Inch W x 1/8 Inch Thk
• Catalog Description: TYPE CTL COPPER TWO-HOLE LUG, SHORT BARREL, MAX 35KV, WIRE SIZE 1/0 STR OR #1 WELD, 5/16 INCH BOLT SIZE, TIN PLATED, DIE COLOR CODE PINK
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Pink Color; 2-11/16 Inch Overall Length; 11/16 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 1/0 AWG Stranded Conductor Size; 5/16 Inch Stud Size; 42H Die Index; 1-3/4 Inch L X 3/4 Inch W X 1/8 Inch Thk Pad Size; 2 Pad Hole(S); 7/8 Inch Pad Hole Spacing; Short, Straight Barrel Type; Application Regular Duty, Conned Area; CTL Model
• Manufacturer: THOMAS & BETTS BLACKBURN
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131235
• SKU Name: ctl102516 blackburn
