Blackburn CTL1-2516 Copper Test Point 2-Hole Lug Short Barrel 1 5/16B Green

Overview

Blackburn CTL1-2516 Copper Test Point 2-Hole Lug Short Barrel 1 5/16B Green

Product Specifications

• UPC: 78378613122
• Pad Size: 1-3/4 INCH L X 21/32 INCH W X 3/32 INCH THK
• Number Of Pad Holes: 2
• Pad Hole Spacing: 7/8 INCH
• Stud Size: 5/16 INCH
• Color: GREEN
• Die Index: 37, 94H
• Material: TIN PLATED SEAMLESS COPPER
• Overall Length: 2-19/32 INCH
• Approval: UL, CSA
• Additional Information: STANDARD PACKAGE 250 PER CARTON
• Catalog Number: CTL1-2516
• Brand Name: Blackburn[R]
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: COPPER
• Conductor Size: 1 AWG STRANDED
• Barrel Type: SHORT
• Barrel Length: 19/32 INCH
• Catalog Description: TYPE CTL COPPER TWO-HOLE LUG, SHORT BARREL, MAX 35KV, WIRE SIZE 1 STR OR #2 WELD, 5/16 INCH BOLT SIZE, TIN PLATED, DIE COLOR CODE GREEN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Green Color; 2-19/32 Inch Overall Length; 19/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 1 AWG Stranded Conductor Size; 5/16 Inch Stud Size; 37, 94H Die Index; 1-3/4 Inch L X 21/32 Inch W X 3/32 Inch Thk Pad Size; 2 Pad Hole(S); 7/8 Inch Pad Hole Spacing; Short Barrel Type; BLACKBURN[R] Brand; Standard Package 250 Per Carton; CTL Model
• Manufacturer: THOMAS & BETTS BLACKBURN
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131228
• SKU Name: ctl12516 blackburn
