Blackburn CTL2-2516 Copper Test Point 2-Hole Lug Short Barrel 2 5/16B Brown

Overview

Blackburn CTL2-2516 Copper Test Point 2-Hole Lug Short Barrel 2 5/16B Brown

Product Specifications

• UPC: 78378613121
• Number Of Pad Holes: 2
• Pad Hole Spacing: 3/4 Inch
• Stud Size: 5/16 Inch
• Color: Brown
• Die Index: 33, 87H
• Material: Tin Plated Seamless Copper
• Overall Length: 2-15/32 Inch
• Approval: UL, CSA
• Additional Information: Application Regular Duty, Conned Area
• Catalog Number: CTL2-2516
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 2 AWG Stranded
• Barrel Type: Short, Straight
• Barrel Length: 19/32 Inch
• Pad Size: 1-5/8 Inch L x 9/16 Inch W x 3/32 Inch Thk
• Catalog Description: TYPE CTL COPPER TWO-HOLE LUG, SHORT BARREL, MAX 35KV, WIRE SIZE 2 STR OR #3 WELD, 5/16 INCH BOLT SIZE, TIN PLATED, DIE COLOR CODE BROWN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Brown Color; 2-15/32 Inch Overall Length; 19/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 2 AWG Stranded Conductor Size; 5/16 Inch Stud Size; 33, 87H Die Index; 1-5/8 Inch L X 9/16 Inch W X 3/32 Inch Thk Pad Size; 2 Pad Hole(S); 3/4 Inch Pad Hole Spacing; Short, Straight Barrel Type; Application Regular Duty, Conned Area; CTL Model
• Manufacturer: THOMAS & BETTS BLACKBURN
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131211
• SKU Name: ctl22516 blackburn
