Blackburn CTL750-58 Copper Test Point 1-Hole Lug Short Barrel 750 5/8B Black

Overview

Blackburn CTL750-58 Copper Test Point 1-Hole Lug Short Barrel 750 5/8B Black

Product Specifications

• UPC: 78378613117
• Number Of Pad Holes: 1
• Stud Size: 5/8 Inch
• Color: Black
• Die Index: 45, 106
• Material: Tin Plated Seamless Copper
• Overall Length: 3-25/32 Inch
• Approval: UL, CSA
• Catalog Number: CTL750-58
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 750 KCMIL
• Barrel Type: Short, Straight
• Barrel Length: 1-1/2 Inch
• Pad Size: 1-9/16 Inch L x 1-29/32 Inch W x 1/4 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 750 KCMIL WIRE, 5/8 BOLT SIZE, TIN PLATED, DIE COLOR CODE BLACK
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Black Color; 3-25/32 Inch Overall Length; 1-1/2 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 750 kcmil Conductor Size; 5/8 Inch Stud Size; 45, 106 Die Index; 1-9/16 Inch L X 1-29/32 Inch W X 1/4 Inch Thk Pad Size; 1 Pad Hole(S); Short, Straight Barrel Type; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131174
• SKU Name: ctl75058 blackburn
