Edwards 116EXMSTA-N5 Hazardous Location, Strobe, Marine, Amber

Overview

Edwards 116EXMSTA-N5 Hazardous Location, Strobe, Marine, Amber

Product Specifications

• Full Technical Description: Strobe Light Type; Cast Aluminum Enclosure Material; UL 1203, UL 1598A, UL 1638, CUL, CSA C22.2 Approval; 120 VAC at 50/60 Hz Operating Voltage; Hazardous/Marine Location Application; Pendant, Ceiling, Stanchion, Bracket Mounting; Class I Div 1 Group C D, Class I Div 2 Group A B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III Div 1 Group E F G, Class III Div 2 Group F G, NEMA 3R/4X Enclosure; Xenon Strobe Lamp Type; Corrosion Resistant, Explosionproof; Epoxy Powder Coated Enclosure Finish; 0.1 Ampere Operating Current; High Impact Glass Dome Lens Material; Amber Lens Color; 65 FPM Flash Rate; 800000 CD Light Intensity; 3000 HR Lamp Life; Includes Dome Guard; 116 Model
• Manufacturer: EDWARDS SIGNALING/SECURITY SYSTEMS/FIRE ALARM SYSTEMS
• Sub Category: Explosionproof Strobe/Flashing Light Fixture
• UPC 12 Digit: 782640220351
• SKU Name: edw 116exmstan5

Resources

• Manufacturer Spec Sheet
