Hubbell B2482 2-Gang Rectangular Steel Wood Floor Box Semi-Adjustable Brass

Overview

Hubbell B2482 2-Gang Rectangular Steel Wood Floor Box Semi-Adjustable Brass

Product Specifications

• UPC: 78358510428
• Material: Stamped Steel
• Number Of Knockouts: 8
• Knockout Size: (2) 1/2 - 1-1/4 Inch Bottom, (2) 1/2 Inch Side, (2) 3/4 Inch Side, (2) 1 Inch Side
• Number Of Gangs: 2
• Service Type: Single Service
• Capacity: 42.5 Cu Inch
• Installation: Wood Floor
• Device Type: Data, Power
• Cover Type: S3625, S3825, S2425, S2625, S2825, S3425, S3826, S3813
• Cover Mounting: Carpet Flange
• Catalog Number: B2482
• Approval: UL, CSA
• Additional Information: Includes Debris Cover, Closure Plug
• Brand Name: ScrubShield[R]
• Type: Semi Adjustable
• Shape: Rectangular
• Length: 6.42 Inch
• Width: 4.5 Inch
• Depth: 3.13 Inch
• Adjustment Size: 1 Inch Maximum D
• Catalog Description: FLUSH WOODEN FLOOR BOX SERIES, 2-GANG, RECTANGULAR, GALVANIZED STAMPED STEEL BOX, SEMI ADJUSTABLE
• Category: Floor Boxes & Accessories
• Full Technical Description: Semi Adjustable Type; Stamped Steel Material; 6.42 Inch; 4.5 Inch; 3.13 Inch; Rectangular Shape; Wood Floor Installation; 2 Gang(S); UL, CSA Approval; S3625, S3825, S2425, S2625, S2825, S3425, S3826, S3813 Cover Type; 42.5 Cu Inch Capacity; Single Service Service Type; (2) 1/2 - 1-1/4 Inch Bottom, (2) 1/2 Inch Side, (2) 3/4 Inch Side, (2) 1 Inch Side Knockout Size; 8 Knockout(S); Data, Power Device Type; Carpet Flange Cover Mounting; 1 Inch Maximum D Adjustment Size; SCRUBSHIELD[R] Brand; Includes Debris Cover, Closure Plug
• Manufacturer: HUBBELL WIRING DEVICE/KELLEMS
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Floor Box
• Unspsc: 39121307
• UPC 12 Digit: 783585104287
• SKU Name: hubw b2482

Resources

• Manufacturer Spec Sheet
• Technical Drawing
