Hubbell HBL27W74 20A/250V Watertight Connector

Overview

Hubbell HBL27W74 20A/250V Watertight Connector

Product Specifications

• UPC: 78358513179
• Number Of Wires: 4
• Material: Thermoplastic Elastomer
• Color: Yellow
• Cord Size: 0.375 to 0.875 Inch Diameter
• Approval: UL 498, CSA C22.2
• Additional Information: Enclosure Rating NEMA 4/4X/12/6/6P; Contact Material Nickel Plated Brass; Temperature Rating -40 to 60 Deg C; Applicable Standard WD-1/6, ANSI
• Catalog Number: HBL27W74
• Brand Name: Twist-Lock[R]
• Type: Polarized
• Constructional Feature: Corrosion Resistant, Water Tight
• Configuration: L14-20R
• Voltage Rating: 125/250 Volt AC
• Current Rating: 20 Amp
• Number Of Poles: 3
• Catalog Description: WATERTIGHT TWIST-LOCK CONNECTOR, 20A, 125/250V AC, 3-POLE, 4 WIRE, THERMOPLASTIC ELASTOMER, NEMA L14-20R
• Category: Plugs,Conn,Inlets,Outlets,Lampholdr
• Full Technical Description: Polarized Type; Thermoplastic Elastomer Material; Yellow Color; L14-20R Configuration; 4 Wire(S); UL 498, CSA C22.2 Approval; 125/250 Volt AC Voltage Rating; 20 Amp Current Rating; 3 Pole(S); Corrosion Resistant, Water Tight; 0.375 to 0.875 Inch Diameter Cord Size; TWIST-LOCK[R] Brand; Enclosure Rating NEMA 4/4X/12/6/6P; Contact Material Nickel Plated Brass; Temperature Rating -40 to 60 Deg C; Applicable Standard Wd-1/6, ANSI
• Manufacturer: Hubbell Wiring Devices-Kellems
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Locking Device Connector
• Unspsc: 39121421
• UPC 12 Digit: 783585131795
• SKU Name: hubw hbl27w74
