Hubbell HBL3433GCB Locking Plug

Overview

Hubbell HBL3433GCB Locking Plug

Product Specifications

• UPC: 78358503990
• Number Of Wires: 4
• Ground Type: Grounding
• Material: Nylon
• Color: Black/White
• Cord Size: 0.35 to 1.15 Inch
• Approval: UL, CSA C22.2
• Additional Information: Wire Size 16 to 8 AWG (Stranded Copper); Enclosure Rating IP20; Contact Material Brass; Temperature Rating -40 to 75 Deg C
• Catalog Number: HBL3433GCB
• Brand Name: Wiring Device-Kellems
• Type: Polarized
• Constructional Feature: Impact/Chemical Resistant
• Configuration: Non-NEMA Locking
• Voltage Rating: 250 Volt AC 3-Phase
• Current Rating: 30 Amp
• Number Of Poles: 3
• Catalog Description: TWIST-LOCK INDUSTRIAL FEMALE CONNECTOR BODY, 30A 3-PHASE DELTA 250V AC, 3-POLE 4-WIRE GROUNDING, NON-NEMA, SCREW TERMINAL
• Category: Plugs,Conn,Inlets,Outlets,Lampholdr
• Full Technical Description: Polarized Type; Nylon Material; Black/White Color; Non-NEMA Locking Configuration; 4 Wire(S); UL, CSA C22.2 Approval; 250 Volt AC 3-Phase Voltage Rating; 30 Amp Current Rating; Grounding; 3 Pole(S); Impact/Chemical Resistant; 0.35 to 1.15 Inch Cord Size; TWIST-LOCK[R], INSULGRIP[R] Brand; Wire Size 16 to 8 AWG (Stranded Copper); Enclosure Rating IP20; Contact Material Brass; Temperature Rating -40 to 75 Deg C
• Manufacturer: Hubbell Wiring Devices-Kellems
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Locking Device Connector
• Unspsc: 39121421
• UPC 12 Digit: 783585039909
• SKU Name: hubw hbl3433gcb

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
