Hubbell HBL5292 Duplex Receptacle Nema5/6-15R

Overview

Hubbell HBL5292 Duplex Receptacle Nema5/6-15R

Product Specifications

• UPC: 78358543540
• Catalog Number: HBL5292
• Device 1: 250 V 15 Ampere 2-Pole 3-Wire Straight Blade, 6-15R
• Device 2: 125 V 15 Ampere 2-Pole 3-Wire Straight Blade, 5-15R
• Color: Brown
• Wiring: Back, Side
• Approval: UL 498, CSA C22.2
• Additional Information: Material Nylon (Face), Reinforced Polyethylene (No Suggestions) (Base); Ground Type Grounding; Temperature Rating -40 to 75 Deg C
• Catalog Description: STRAIGHT BLADE RECEPTACLE, COMBO DUPLEX, COMMERCIAL/INDUSTRIAL GRADE, 2-POLE 3-WIRE GROUNDING, 15A 125V AND 250V, 5-15R AND 6-15R
• Category: Receptacles & Surge Protectors
• Full Technical Description: Brown Color; UL 498, CSA C22.2 Approval; Back, Side Wiring; 250 V 15 Ampere 2-Pole 3-Wire Straight Blade, 6-15R Device 1; 125 V 15 Ampere 2-Pole 3-Wire Straight Blade, 5-15R Device 2; Material Nylon (Face), Reinforced Polyethylene (No Suggestions) (Base); Ground Type Grounding; Temperature Rating -40 to 75 Deg C
• Manufacturer: Hubbell Wiring Devices-Kellems
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Combination Duplex Receptacle
• Unspsc: 39121406
• UPC 12 Digit: 783585435404
• SKU Name: hubw hbl5292

Resources

• Manufacturer Spec Sheet
