Hubbell IG5461 Single Receptacle, Isolated Ground, 20A 250V, 6-20R, Orange

Overview

Hubbell IG5461 Single Receptacle, Isolated Ground, 20A 250V, 6-20R, Orange

Product Specifications

• UPC: 78358588050
• Number Of Wires: 3
• Ground Type: Isolated Grounding
• Material: Nylon (Face), Polybutylene Terephthalate (Base)
• Color: Orange
• Wiring: Back, Side
• Grade: Extra Heavy-Duty, Specification
• Approval: UL 498, CSA
• Additional Information: Contact/Strap Material Brass; Operating Temperature -40 to 75 Deg C
• Catalog Number: IG5461
• Brand Name: SpikeShield[R], HBL[R]
• Type: Single
• Constructional Feature: Impact Resistant
• Configuration: 6-20R
• Voltage Rating: 250 V
• Current Rating: 20 Ampere
• Number Of Poles: 2
• Catalog Description: STRAIGHT BLADE DEVICES, RECEPTACLES, SINGLE, SPECIFICATION GRADE, 2-POLE 3-WIRE GROUNDING, 20A 250V, 6-20R, ORANGE, SINGLE PACK
• Category: Receptacles & Surge Protectors
• Full Technical Description: Single Type; Nylon (Face), Polybutylene Terephthalate (Base) Material; Orange Color; 6-20R Configuration; 3 Wire(S); Extra Heavy-Duty, Specification Grade; UL 498, CSA Approval; 250 V Voltage Rating; 20 Ampere Current Rating; Isolated Grounding; 2 Pole(S); Impact Resistant; Back, Side Wiring; SPIKESHIELD[R], HBL[R] Brand; Contact/Strap Material Brass; Operating Temperature -40 to 75 Deg C
• Manufacturer: HUBBELL WIRING DEVICE/KELLEMS
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Duplex/Single Receptacle
• Unspsc: 39121406
• UPC 12 Digit: 783585880501
• SKU Name: hubw ig5461

Resources

• Manufacturer Spec Sheet
• Product Spec Sheet
