Hubbell L715C Locking 15A 277V Non-Metallic L7-15R Connector

Overview

Hubbell L715C Locking 15A 277V Non-Metallic L7-15R Connector

Product Specifications

• UPC: 78358583573
• Ground Type: Grounding
• Material: Nylon
• Color: Black/White
• Cord Size: 0.3 to 0.655 Inch
• Approval: UL 94/498, CSA C22.2
• Additional Information: Temperature Rating -40 to 60 Deg C
• Catalog Number: L715C
• Model: L7
• Type: Polarized
• Configuration: L7-15R
• Voltage Rating: 277 V
• Current Rating: 15 Ampere
• Number Of Poles: 2
• Number Of Wires: 3
• Catalog Description: LOCKING DEVICES, SELECT SPEC TWIST-LOCK, COMMERCIAL/INDUSTRIAL, FEMALE CONNECTOR BODY, 15A 277V AC, 2-POLE 3- WIREGROUNDING, L7-15R, SCREWTERMINAL, BLACK
• Category: Plugs,Conn,Inlets,Outlets,Lampholdr
• Full Technical Description: Nylon Material; Black/White Color; NEMA L7-15R Configuration; 3 Wire(S); UL 498, CSA C22.2 Approval; 277 Volt AC Voltage Rating; 15 Amp Current Rating; Grounding; 2 Pole(S); 0.3 to 0.655 Inch Cord Size; HUBBELL-PRO[R] Brand; RoHS Compliant; Enclosure Rating NEMA 1; Contact Material Brass; Operating Temperature -40 to 60 Deg C; Applicable Standard Federal Specification WC-596
• Manufacturer: Hubbell Wiring Devices-Kellems
• Manufacturer Brand: Hubbell Wiring Devices-Kellems
• Sub Category: Locking Device Connector
• Unspsc: 39121421
• UPC 12 Digit: 783585835730
• SKU Name: hubw l715c

Resources

• Manufacturer Spec Sheet
• Technical Line Drawing
