ILSCO CSWD-4/0-12-1 2-Hole Copper Lug

Overview

Ilsco CSWD-4/0-12-1 2-Hole Copper Lug

Product Specifications

• UPC: 78366964045
• Pad Size: 2.125 INCH L X 0.999 INCH W X 0.141 INCH THK
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1 INCH
• Stud Size: 1/2 INCH
• Color: PURPLE
• Die Index: I-54
• Material: SEAMLESS ELECTRO TIN PLATED COPPER
• Overall Length: 3.491 INCH
• Approval: UL, CSA
• Additional Information: INNER DIAMETER 0.546 INCH; OUTER DIAMETER 0.687 INCH; WITH CHAMFERED TYPE CABLE ENTRY
• Catalog Number: CSWD-4/0-12-1
• Brand Name: SureCrimp[R]
• Model: CSWD
• Voltage Rating: 35 KV
• Conductor Material: COPPER
• Conductor Size: 4/0 AWG
• Barrel Type: STANDARD
• Barrel Length: 0.875 INCH
• Catalog Description: SURECRIMP COPPER COMPRESSION LUG, CONDUCTOR SIZE 4/0, 2 HOLES, 1/2IN BOLT SIZE, 1IN HOLE SPACING, STANDARD BARREL, SIGHT WINDOW, TIN PLATED, UL, CSA
• Category: Large Terminals & Connectors
• Full Technical Description: Seamless Electro Tin Plated Copper Material; Purple Color; 3.491 Inch Overall Length; 0.875 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 4/0 AWG Conductor Size; 1/2 Inch Stud Size; I-54 Die Index; 2.125 Inch L X 0.999 Inch W X 0.141 Inch Thk Pad Size; 2 Pad Hole(S); 1 Inch Pad Hole Spacing; Standard Barrel Type; SURECRIMP[R] Brand; Inner Diameter 0.546 Inch; Outer Diameter 0.687 Inch; With Chamfered Type Cable Entry; CSWD Model
• Made In Usa: Yes
• Manufacturer: ILSCO CORP
• Manufacturer Brand: ILSCO Corp.
• Proposition 65 Warning (Ca): This product is in compliance with Prop65; it is not known to contain any chemicals associated with this regulation
• Sub Category: Compression Cable Lug
• Unspsc: 39121448
• UPC 12 Digit: 783669640458
• SKU Name: ilsco cswd4/0121
